High-Voltage Step-Up Trigger RM8 Pulse Transformer Coil for Electronic Equipment

Dielectric Withstand Voltage (Hi-Pot) : Reinforced isolation testing up to AC 4kV for high-voltage safety.

Model Number : RM8

Packaging Details : Small transformers: blister tray packaging + export cartons; Large transformers packed on wooden pallets. Custom packaging available upon request.

Stray Capacitance & Leakage Control : Precision winding technology engineered for extremely low leakage inductance and fast pulse rise times.

MOQ : 100PCS

Delivery Time : 7-22 wark days

Payment Terms : T/T

Core Material & Permeability : High-grade ferrite cores (PC40, PC95, TP4) selectable based on frequency and saturation requirements.

Brand Name : CHIPSEN

Operating Frequency Range : Optimized for wideband operations from 20KHZ-300KHZ with low core loss.

Place of Origin : China

Mounting & Package Type : Vertical / Horizontal through-hole (DIP) or customized surface-mount (SMD) profiles for space-constrained PCBs.

Price : $0.8 - 2/ Piece,1000-10000pcs

Supply Ability : 5000 pcs per day

Insulation & Thermal Class : Class B (130℃) or Class F (155℃) insulation systems with custom tape wrapping options.

Certification : UL/cUL Class B/F/H, VDE, CQC

Contact Now

RM8 High-Frequency Pulse Transformer & Trigger Coil
1. Product Overview

The RM8 High-Frequency Pulse Transformer is a high-performance magnetic component engineered for precision voltage step-up and trigger applications. Featuring a compact RM8 core structure and reliable insulation, it delivers exceptional magnetic coupling and stable switching performance for modern power electronics.

Parameter Category Specification Item Standard / Typical Range
Core & Structure Core Type & Material RM8 Ferrite Core (PC40 / PC95 / TP4)
Electrical Performance Inductance (Lm) 1.0mH - 15.0mH (Typical)
Electrical Performance Turns Ratio (Np : Ns) 1:1, 1:2, or Custom Ratios
Electrical Performance Working Frequency 20kHz - 300kHz
Safety & Insulation Hi-Pot / Dielectric Strength AC 1.5kV - 4.0kV (1mA, 1min)
Safety & Insulation Insulation Class Class B (130°C) / Class F (155°C)
Physical & Mounting Pin Layout & Dimensions Standard RM8 vertical/horizontal (4+4 / 5+5 pins)
Environmental Operating Temperature -40°C to +125°C
2. Key Features

  • Compact RM8 Core Design: Space-saving footprint tailored for high-density PCB layouts.

  • High Efficiency & Low Loss: Premium core materials ensure minimal energy loss and low operating temperatures.

  • Precise Trigger Performance: Delivers accurate pulse signals and stable high-voltage step-up capabilities.

  • UL Certified Quality: Built to strict international safety and electrical standards for long-term reliability.

3. Product Applications

Widely used across various electronic and industrial systems, including:

  • Switched-Mode Power Supplies (SMPS)

  • Inverters and Converters

  • Industrial Control and Automation Equipment

  • Lighting and Ignition Trigger Circuits

  • Communication and Consumer Electronics

  • High-Voltage Step-Up Trigger RM8 Pulse Transformer Coil for Electronic Equipment
4. Why Choose Us
Company Advantages

  • Direct Manufacturer Pricing: Competitive factory-direct costs without middleman markups.

  • Robust Production Capacity: Advanced manufacturing lines ensuring stable supply chains and on-time delivery.

  • Strict Quality Control: 100% full inspection and testing prior to shipment to guarantee zero-defect standards.

Product Advantages

  • Customized Solutions: Flexible OEM/ODM services tailored to your specific electrical requirements.

  • Global Standard Compliance: Fully certified (UL, RoHS) for hassle-free worldwide integration.

  • Proven Durability: High thermal stability and resistance to electromagnetic interference (EMI).

  • High-Voltage Step-Up Trigger RM8 Pulse Transformer Coil for Electronic Equipment

Product Tags:

High-Voltage Step-Up Trigger Coil



RM8 Pulse Transformer for Electronics



Flyback Transformer High Frequency


High-Voltage Step-Up Trigger RM8 Pulse Transformer Coil for Electronic Equipment Manufactures

High-Voltage Step-Up Trigger RM8 Pulse Transformer Coil for Electronic Equipment Images
